Funkwerk W1002 User Manual

Chapter 9 Physical interfaces
9.1 Ethernet Ports
An Ethernet interface is a physical interface for connection to the local network or external
networks.
Note
In the ex works state, the Ethernet ports ETH1 and ETH2 are assigned to the standard
bridge group br0, which is configured as DHCP client and with the fallback IP ad-
dress 192.168.0.252 and Netmask 255.255.255.0.
9.1.1 Port Configuration
Your device allows you to configure the two Ethernet interfaces separately.
Fig. 53: Physical Interfaces->Ethernet Ports->Port Configuration
The Physical Interfaces -> Ethernet Ports -> Port Configuration menu consists of the
following fields:
Fields in menu Port Configuration
Field Description
Port Shows the respective port. The numbering corresponds to the
9 Physical interfaces Funkwerk Enterprise Communications GmbH
118 bintec W1002/W1002n/W2002/WIx040/WIx065
