Pin Function Eth1 - PoE Function Eth 2
5 Power Not used
6 RD -/Power RD -
7 Power Not used
8 Power Not used
The Ethernet 10/100 BASE-T interface does not have an Auto-MDI-X function.
6.1.5.2 Serial Interface
Your device has a Serial interface for connection to a console. This supports Baud rates
from 1200 to 115200 Bps.
The interface is designed as a 9-pin SUB-D socket.
Fig. 17: 9-pin Sub-D connector
The pin assignment is as follows:
Pin assignment of the Sub-D port
Pin bintec W1002/bintec W2002
function
bintec W1002n function
1 CD Not used
2 RxD RxD
3 TxD TxD
4 DTR Not used
5 GND GND
6 DSR DSR
7 RTS RTS
8 CTS CTS
9 RI Not used
6.1.6 Frequencies and channels
Different certification regulations apply around the world. ETSI standards generally apply
(predominantly used in Europe). For operation in Europe, please read the notes in the
R&TTE Compliance Information.
Funkwerk Enterprise Communications GmbH
6 Technical data
bintec W1002/W1002n/W2002/WIx040/WIx065 35
