the broadcast address of the first LAN interface (default setting) or to an explicitly entered
IP address. One packet is sent per time interval, which can be adjusted individually to val-
ues from 1 - 60 seconds. Up to 100 physical and virtual interfaces can be monitored,
provided the packet size of 4096 bytes is not exceeded. The Activity Monitor on your PC
receives the packets and can display the information contained in them in various ways ac-
cording to the configuration.
Activate the Activity Monitor as follows:
• configure the relevant device(s) to be monitored.
• Start and configure the Windows application on your PC (see BRICKware for Windows ,
see www.funkwerk-ec.com).
18.5.1 Options
Fig. 159: External Reporting->Activity Monitor->Options
The External Reporting -> Activity Monitor -> Options menu consists of the following
fields:
Fields in the Options Basic Parameters menu
Field Description
Monitored interfaces Select the type of information to be sent in the UDP packets to
the Windows application.
Possible values:
Funkwerk Enterprise Communications GmbH
18 External Reporting
bintec W1002/W1002n/W2002/WIx040/WIx065 351
