Field in the IPSec Statistics Peers menu
Field Description
State Displays the number of IPSec connections by their current
status.
• Active: Currently active IPSec connections.
• Enable: IPSec connections currently in the tunnel setup
phase.
• Blocked: IPSec connections that are blocked.
• Dormant: Currently inactive IPSec connections.
• Configured: Configured IPSec connections.
Field in the IPSec Statistics SAs menu
Field Description
IKE (Phase1) Shows the number of active phase 1 SAs (Established) from
the total number of phase 1 SAs (Total).
IPSec (Phase2) Shows the number of active phase 2 SAs (Established) from
the total number of phase 2 SAs (Total).
Field in the IPSec Statistics Packet Statistics menu
Field Description
Total Shows the number of all processed incoming (Incoming) or
outgoing (Outgoing) packets.
Passed Shows the number of incoming (Incoming) or outgoing (Outgo-
ing) packets forwarded in plain text.
Dropped Shows the number of rejected incoming (Incoming) or outgoing
(Outgoing) packets.
Encrypted Shows the number of IPSec protected incoming (Incoming) or
outgoing (Outgoing) packets.
Error Shows the number of incoming (Incoming) or outgoing (Outgo-
ing) packets for which the processing led to errors.
19.3 Interfaces
Funkwerk Enterprise Communications GmbH
19 Monitoring
bintec W1002/W1002n/W2002/WIx040/WIx065 357
