The pin assignment is as follows:
Pin assignment of the Sub-D port
Pin Function
1 CD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
6.2.6 Frequencies and channels
Different certification regulations apply around the world. ETSI standards generally apply
(predominantly used in Europe). For operation in Europe, please read the notes in the
R&TTE Compliance Information.
6.3 bintec WI1065, WI2065 and WI3065
6.3.1 Scope of supply
Your device is supplied with the following parts:
• Cable sets:
- Serial cable (D-SUB9)
- Ethernet cable (RJ-45, STP)
• Blind stops for SFP
• Installation material
- SD slot cover with screws
- 3-pole screw terminal bar for the power supply
- 2-pole screw terminal bar for relay
6 Technical data Funkwerk Enterprise Communications GmbH
44 bintec W1002/W1002n/W2002/WIx040/WIx065
