Field Description
(active), i.e. a connection already exists to the L2TP partner.
DNS Negotiation Select whether your device receives IP addresses for primary
DNS server, secondary DNS server, primary WINS and sec-
ondary WINS from the L2TP partner or sends these to the
L2TP partner.
The function is activated with Enabled.
The function is enabled by default.
14.2.3 Options
Fig. 107: VPN->L2TP->Options
The VPN -> L2TP -> Options menu consists of the following fields:
Fields in the Options Global Options menu
Field Description
UDP Destination Port Enter the port to be monitored by the LNS on incoming L2TP
tunnel connections.
Available values are all whole numbers from 1 to 65535, the
default value is 1701, as specified in RFC 2661.
Funkwerk Enterprise Communications GmbH
14 VPN
bintec W1002/W1002n/W2002/WIx040/WIx065 253
