19.3.1 Statistics
In the Monitoring -> Interfaces -> Statistics menu, the current values and activities of all
device interfaces are shown.
Fig. 164: Monitoring -> Interfaces -> Statistics
You change the status of the interface by pressing the button or button in the Action
column. Press the button to display the statistical data for the individual interfaces in de-
tail.
Values in the list Statistics
Field Description
# Shows the serial number of the interface.
Description Displays the name of the interface.
Type Displays the interface text.
Tx Packets Shows the total number of packets sent.
Tx Bytes Displays the total number of octets sent.
Tx Errors Shows the total number of errors sent.
Rx Packets Shows the total number of packets received.
Rx Bytes Displays the total number of bytes received.
Rx Errors Shows the total number of errors received.
State Shows the operating status of the selected interface.
19 Monitoring Funkwerk Enterprise Communications GmbH
358 bintec W1002/W1002n/W2002/WIx040/WIx065
