Chapter 10 LAN
In this menu, you configure the addresses in your LAN and can structure your local network
using VLANs.
10.1 IP configuration
The IP configuration of the bridge groups can be edited in this menu.
10.1.1 Interfaces
In the LAN IP Configuration Interfaces menu, the available IP interfaces are listed. You
can edit the IP configuration of the interfaces or create virtual interfaces for special applica-
tions. Interfaces are also listed here once you have created them in the subsystems
(wireless networks, bridge lines, WDS links), and then set them to routing mode in the Sys-
tem Management Interface Mode / Bridge Groups Interfaces menu.
Use the to edit the settings of an existing interface (bridge groups, Ethernet interfaces in
routing mode).
You can use the New button to create virtual interfaces. However, this is only needed in
special applications (e.g. BRRP).
Depending on the option selected, different fields and options are available. All the config-
uration options are listed below.
The default setting for all existing interfaces of your device is Bridging mode. In the ex
works state the bridge group br0 is pre-configured as a DHCP client with the fallback IP ad-
dress 192.168.0.252 and netmask 255.255.255.0.
Note
Please note:
If your device has obtained an IP address dynamically from a DHCP server operated
in your network for the basic configuration, the fallback IP address 192.168.0.252 is
deleted automatically and your device will no longer function over this address.
However, if you have set up a connection to the device over the fallback IP address
192.168.0.252 or have assigned an IP address with the ComPoint Manager in the ba-
sic configuration, you will only be able to access your device over this IP address. The
10 LAN Funkwerk Enterprise Communications GmbH
126 bintec W1002/W1002n/W2002/WIx040/WIx065
