Page #377 background imageLoading...
Page #377 background image
Field Description
Noise dBm Shows the received noise strength in dBm.
SNR dB Signal-to-Noise Ratio in dB is an indicator of the quality of the
wireless connection.
Values:
• > 25 dB excellent
• 15 – 25 dB good
• 2 – 15 dB borderline
• 0 – 2 dB bad.
Data Rate Mbps Shows the current transmission rate of data received by this cli-
ent in Mbit/s. The following transmission rates are possible:
IEEE 802.11b: 11, 5.5, 2 and 1 mbit; IEEE 802.11g/a:
54,48,36,24,18,12,9,6 mbit. If the 5 GHz frequency band is
used, the display of 11, 5.5, 2 and 1 mbit is suppressed for
IEEE 802.11b.
Rate Displays the possible data rates on this wireless module.
Tx Packets Shows the number of sent packets for the data rate.
Rx Packets Shows the number of received packets for the data rate.
19.4.3 WDS
In the Monitoring -> WLAN -> WDS menu, the current values and activities of the con-
figured WDS links are shown.
Funkwerk Enterprise Communications GmbH
19 Monitoring
bintec W1002/W1002n/W2002/WIx040/WIx065 365
