Fig. 172: Monitoring -> WLAN -> WDS
Values in the list WDS
Field Description
WDS description Shows the name of the WDS link.
Remote MAC Shows the MAC address of the WDS link partner.
Uptime Shows the time in hours, minutes and seconds for which the
WDS link in question is active.
Tx Packets Shows the total number of packets sent.
Rx Packets Shows the total number of packets received.
Signal dBm Shows the received signal strength in dBm.
Noise dBm Shows the received noise strength in dBm.
Data Rate Mbps
Shows the current transmission rate of data received on this
WDS link in Mbit/s.
If required, the Test link can be used to start a link test. The test is only available for funk-
werk devices and only if the WDS link is active.
The link test provides all the data necessary for checking the quality of the WDS link. The
link test also helps you to align the antennas. This option is only displayed if the link is en-
abled.
WDS Link Details
You use the icon to open an overview of further details for the WDS links.
19 Monitoring Funkwerk Enterprise Communications GmbH
366 bintec W1002/W1002n/W2002/WIx040/WIx065
