Property Value
devices must be earthed.
24V DC 1,1A ± 30 % with reverse voltage protec-
tion, insulated 3-pole
PoE on Ethernet 1 Class 0 (insulated) with max.
two WLAN modules
Protection against theft Theft protection is available as an option
Temperature sensor Temperature monitoring and software-controlled
actions possible
Environmental requirements:
Storage temperature -25 °C to +85 °C
Operating temperature -25 °C to +70 °C
Relative atmospheric humidity 10 % to 95 % (non-condensing)
Room classification
Operate only in dry rooms
Available interfaces:
Serial interface V.24 Permanently installed, supports Baud rates: 1200,
2400, 4800, 9600, 19200, 38400, 57600, 115200
Baud
Ethernet IEEE 802.3 LAN Permanently installed (twisted pair only), 10/100
mbps, autosensing, MDI/MDIX 2x 10/100 Base T/
TX
MMC/SD card slot Save and load of configuration via MMC/SD card
possible (optional, in preparation)
Relay An alarm using relay is possible in the event of
overtemperature or error: potential-free working
contact, 1A 125V AC / 2A 30 V DC
Optical interface Module slot for optical interface 100 mbps LWL
Single Mode LC or LWL Multimode LC - 1x 100
Base FX/SX with SFP module
Available sockets:
Serial interface V.24 9-pin Sub-D connector
MMC/SD card slot With protective cover if card is inserted.
Relay switching contact N/O 30V AC/DC 0.5 A potential-free, software configur-
able, switchable
Ethernet interface RJ45 socket
6 Technical data Funkwerk Enterprise Communications GmbH
38 bintec W1002/W1002n/W2002/WIx040/WIx065
