WACN ID
Wide Area Communication Network
IDentity
SYSTEM ID
System IDentity
WUID
Working Unit IDentity
WGID
Working Group IDentity
RFSS
RF Sub-System IDentity
SITE ID
Site IDentity
IDEN-UP
This selects which IDEN_UP TSBK format
will be transmitted the control channel.
None
No IDEN_UP TSBK is transmitted on the
control channel.
800 MHz
The 8/700 MHz format IDEN_UP TSBK is
transmitted. It defines the following band:
Field Value
IDEN_UP TSBK Value
Identifier 1 %0001
Bandwidth 12.5 kHz 0x64
Transmit
Offset
-45 MHz 0xB4
Channel
Spacing
6.25 kHz 0x32
Base
Frequency
851.00625 0xA2510A2
700 MHz
The 8/700 MHz format IDEN_UP TSBK is
transmitted. It defines the following band:
Field Value
IDEN_UP TSBK Value
Identifier 2 %0010
Bandwidth 12.5 kHz 0x64
Transmit
Offset
+30 MHz 0x178
Channel
Spacing
6.25 kHz 0x32
Base
Frequency
762.00625 0x9157562
UHF/VHF
The UHF/VHF MHz format IDEN_UP TSBK
is transmitted. The UHF/VHF Config screen
is used to define the IDEN_UP parameters.
The middle of the Display Zone contains a
field named SEQ. This area of the display,
also known as a thermometer will update the
user as to the state of the call sequence. Refer
to Appendix M for a description of the status
thermometer signaling events for each test
sequence.
The bottom portion of the Display Zone
contains those parameters received from the
radio under test. The parameters received
from the radio are defined as follows.
WACN ID
Wide Area Communication Network IDentity
SYSTEM ID –
System IDentity
WUID
Working Unit IDentity
WGID
Working Group IDentity
298
