GPT-10000 Series User Manual
110
4. The AUTO test file name is set when the
current AUTO test is saved or when the cursor
is moved to another setting.
Adding a Step to the AUTO Test
Background
Up to 10 MANU tests (steps) can be added to
an automatic (AUTO) test. Each step is added
in a sequential order.
Steps
1. Press the DOWN arrow key to
bring the cursor to the MANU
STEP number.
MANU STEP number cursor
2. Use the scroll wheel to choose a
MANU STEP number to add to the
automatic test.
MANU STEP number
001~100, CON
CON
It indicates that this group of AUTO test
can be connected with the next group.
Refer to page 112 for more details.
