GW Instek GPT-10000 Series User Manual

REMOTE CONTROL
229
Parameter/
Return parameter
<NR2>
0.050 ~ 6.100 (kV), 12.1(kV) for 15012
Example
MANU:DCW:VOLT 6
Sets the DCW voltage to 6 kV.
MANU:DCW:CHISet
Set
Query
Description
Sets or returns the DCW HI SET current value in
milliamps. The test must first be in DCW mode
before this command can be used.
Note: An “Err” message will be shown on display
if the DCW Voltage X (HI SET value + REF) is > 50
watts for GPT-12XXX or the DCW Voltage X HI
SET value + REF is > 100 watts for GPT-15XXX or
the DCW Voltage X HI SET value + REF is > 120
watts for GPT-15012. An “DC Over 50W” or “DC
Over 100W” or “DC Over 120W” message will be
returned after using the query command
“SYSTem:ERRor ?” in remote control.
Syntax
Query Syntax
MANU:DCW:CHISet <NR2>
MANU:DCW:CHISet?
Parameter/
Return parameter
<NR2>
0.001 ~ 11.00 (mA) [GPT-12XXX/15012]
0.001 ~ 21.00 (mA) [GPT-15XXX]
Example
MANU:DCW:CHIS 5
Sets the DCW HI SET current to 5mA.
MANU:DCW:CLOSet
Set
Query
Description
Sets or returns the DCW LOW SET current value
in milliamps. The LOW SET value must be less
than the HI SET value. The test must first be in
DCW mode before this command can be used.
The LOW SET range must use the HI SET range. If
all the digits in the LOW SET range are outside the
HI SET range, an Err will be produced. All digits
