GW Instek GPT-10000 Series User Manual

OPERATION
69
Setting GB Contact
Background
Basically, GB test has no ramp up time and thus
starts from the set test time by user directly.
However, due to some cases where a buffer
time before test time is in fact required for GB
test, e.g., in conveyor where DUTs are tested for
GB by batches and certain buffer duration
needed for test leads or jigs connecting with
DUTs, the GB CONTACT setting practically
allows user to apply to customized scenarios
when necessary occurs.
Note
GB CONTACT setting is only applicable to GB test.
Steps
1. Press the UP / DOWN arrow soft-
keys to bring the cursor to the GB
CONTACT setting.
GB CONTACT cursor
2. Use the scroll wheel to set the
value of GB CONTACT
GB CONTACT
000.0 s ~ 999.9 s
