Remote Controller Operation
Description
The GPT-10000 accepts external remote
controllers with a START and STOP button. To
use the REMOTE terminal, the GPT-10000 must
first be configured to accept a remote controller.
Operating a remote controller is the same as
operating the START and STOP buttons on the
front panel.
Steps
1. Insert the lead of remote controller
into the REMOTE terminal.
REMOTE
2. Configure the CONTROL option to
REMOTE in the SYSTEM mode.
Page 144
3. The tester will now only be able to
start a test using a remote
controller.
NOTE
Even if the GPT-10000 is configured to use the
REMOTE option, the STOP button on the front
panel can still be used to stop a test.
4. To return the operation control to
the front panel, configure the
CONTROL option to Front Panel.
Page 144
