REMOTE CONTROL
211
MEASure<x>
Query
Description
Returns the test parameters & results of the tester
in either MANU or AUTO mode.
MANU mode: Returns the test parameters &
results of a MANU test.
AUTO mode: Returns the test parameters & results
of the selected step (1-50) of the AUTO test.
Return parameters: Function, Status, Test Value1,
Test Value2, Test Time.
Query Syntax
MEASure<x>?
Parameter
(MANU mode)
No parameter needed for MANU
mode.
Parameter
(AUTO mode)
<x>
<NR1>1~50. MANU Step
number.
Return parameter
<string>
Returns the test status of the test
in the following format:
Function, Status, Test Value1,
Test Value2, Test Time.
Function
ACW, DCW, IR, GB, CON
Status
Refer to the table with affiliated
contents below for details
Test Value1
Voltage+unit
Test Value2
Current+unit
Resistance+unit
Test Time
I= Initial Time+s
R=Ramp Time+s
T=Test Time+s
D=Ramp Down Time+s
