REMOTE CONTROL
227
MANU:ACW:REF
Set
Query
Description
Sets or returns the ACW reference value in uA or
mA. The test must first be in ACW mode before
this command can be used.
The ACW reference value shares the identical limit
of HI SET value, which is 42mA at the maximum.
For instance, when HI SET value is set 10mA, the
reference value can therefore be set up to 32mA.
Note: An “Err” message will be shown on display
if the Ramp Time + Test Time is > 240 seconds
when the HI SET limit + REF is ≥ 30mA for GPT-
12XXX or HI SET limit + REF is ≥ 80mA for GPT-
15XXX. This applies to the ACW function only. An
“TIME OVER 240s” message will be returned after
using the query command “SYSTem:ERRor ?” in
remote control.
Syntax
Query Syntax
MANU:ACW:REF <NR2>
MANU:ACW:REF?
Parameter/
Return parameter
<NR2>
0.000 ~ 41.99 (mA) [GPT-12XXX]
0.000 ~ 109.9 (mA) [GPT-15XXX]
Example
MANU:ACW:REF 40
Sets the ACW reference to 40 mA.
MANU:ACW:INITvoltage
Set
Query
Description
Sets or returns the ACW percentage of initial
voltage. The test must first be in ACW mode
before this command can be used.
Syntax
Query Syntax
MANU:ACW:INITvoltage <NR1>
MANU:ACW:INITvoltage?
Parameter/
Return parameter
<NR1>
0 ~ 99%
