GW Instek GPT-10000 Series User Manual

GPT-10000 Series User Manual
220
MANU:ACW:CHISet
Set
Query
Description
Sets or returns the ACW HI SET current value in
milliamps. The test must first be in ACW mode
before this command can be used.
Note: An “Err” message will be shown on display
if the Ramp Time + Test Time is > 240 seconds
when the HI SET limit + REF is ≥ 30mA for GPT-
12XXX or HI SET limit + REF is ≥ 80mA for GPT-
15XXX. This applies to the ACW function only. An
“TIME OVER 240s” message will be returned after
using the query command “SYSTem:ERRor ?” in
remote control.
Syntax
Query Syntax
MANU:ACW:CHISet <NR2>
MANU:ACW:CHISet?
Parameter/
Return parameter
<NR2>
0.001 ~ 42.00 (mA) [GPT-12XXX]
0.001 ~ 110.00 (mA) [GPT-15XXX]
Example
MANU:ACW:CHIS 30.0
Sets the ACW HI SET current to 30 mA.
