OPERATION
57
ACW
DCW
IR
GB
CONT
000uA~ 41.99mA (GPT-12XXX)
*HI SET + REF value ≤ 42.00mA
000uA~ 109.9mA (GPT-15XXX)
*HI SET+REF value ≦ 110.0mA
000uA~ 10.99mA (GPT-12XXX/15012)
*HI SET + REF value ≤ 11.00mA
000uA~ 20.99mA (GPT-15XXX)
*HI SET+REF value ≦ 21.00mA
000.0MΩ~50.00GΩ
000.0mΩ~650.0mΩ
*ISET x (HI SET + REF value) is no
greater than 7.2V
00.00Ω~80.00Ω
*ISET(100mA) x (HI SET + REF
value) is no greater than 8V
Note
For IR test, a reference value of tester can be
automatically created via the GND OFFSET
function. See page 68 for details.
For GB and CONT tests, a reference value of test
lead can be automatically created via the ZERO
CHECK function. See page 71 for details.
Setting an Initial Voltage
Background
In essence, the test voltage for both ACW and
DCW will gradually and linearly rise up, from
zero, to the target set voltage in accord with the
set RAMP TIME ahead of the TEST TIME.
Nevertheless, under certain circumstances, user
may have preferences on the percentage of
starting test voltage. Therefore, the INIT
VOLTAGE provides another alternative for
different applications on user side.
