GPT-10000 Series User Manual
228
MANU:ACW:INIT 87
Sets the ACW Initial Voltage to 87%.
MANU:ACW:CONTact
Set
Query
Sets or returns the CONTACT CHK function on or off.
Note: An “Err” message will be shown on display
if the learned reference value is less than 30uA. An
LEARNING < 30uA message will be returned
after using the query command
“SYSTem:ERRor ?” in remote control.
MANU:ACW:CONTact {ON|OFF}
MANU:ACW:CONTact?
ON
CONTACT CHK in ACW test ON
OFF
CONTACT CHK in ACW test OFF
MANU:ACW:CONT OFF
Sets the CONTACT CHK off in ACW test.
MANU:DCW:VOLTage
Set
Query
Sets or returns the DCW voltage in kV. The test
must first be in DCW mode before this command
can be used.
Note: An “Err” message will be shown on display
if the DCW Voltage X (HI SET value + REF) is > 50
watts for GPT-12XXX or the DCW Voltage X HI
SET value + REF is > 100 watts for GPT-15XXX or
the DCW Voltage X HI SET value + REF is > 120
watts for GPT-15012. An “DC Over 50W” or “DC
Over 100W” or “DC Over 120W” message will be
returned after using the query command
“SYSTem:ERRor ?” in remote control.
MANU:DCW:VOLTage <NR2>
MANU:DCW:VOLTage?
