APPENDIX
267
Tester Errors
The following test error messages highlighted in red may appear on the
GPT-10000 display when completing a running test.
Test result is beyond the HI SET value
Test result is below the LOW SET value
Measured voltage is beyond the set value by 1.1 times
Measured voltage is below the set value by 0.9 time
Voltage short-circuit detected
Measured current is beyond the set value by 1.1 times
Measured current is below the set value by 0.9 time
Measured GB voltage is beyond 7.2V
Measured CONT voltage is beyond 8.0V
Ground current abnormality detected
CONTACT CHK greater than HI Limit detected
CONTACT CHK lower than LOW Limit detected
The following setup error messages highlighted in red may appear on
the GPT-10000 display when abnormality occurs in the settings of
MANU steps.
Setting error in MANU STEP value
Setting error in MANU NAME
Setting error in HI SET value
Set value of HI SET is less than or equal to
LOW SET value
To Next Page
