GW Instek GPT-10000 Series User Manual

GPT-10000 Series User Manual
48
2. Use the scroll wheel to set the
TEST TIMER value.
ACW
DCW
IR
GB
CONT
OFF, 000.3s~999.9s
OFF, 000.3s~999.9s
000.3s~999.9s
000.3s~999.9s
000.3s~999.9s
Note
With the ACW test function, when the test current
is beyond 30mA, the Ramp Up Time + Test Time
cannot exceed 240 seconds. At this current level,
the tester also needs to pause after a test for a
time equal to or greater than the output time.
Turn Off Test
Time
When in either ACW or DCW test, the TEST
TIME can be turned off, which means the test
without test time will last infinitely until FAIL
judgment occurs.
Identical with the regular setting
for TEST TIME, turn off the timer
by using the scroll wheel to set
OFF for TEST TIME value.
TEST TIME OFF
