Figure 10-3 48SFF front panel
(1) Serial label pull tab module (2) USB 2.0 connectors
(3) VGA connector (4) Compute module 1
(5) SAS/SATA drive or diagnostic panel (optional) (6) USB 3.0 connector
(7) Compute module 2
Figure 10-4 32SFF front panel
(1) Serial label pull tab module (2) USB 2.0 connectors
(3) VGA connector (4) Drive cage bay 1
(5) Compute module 1 (6) Drive cage bay 2
(7) SAS/SATA drive, NVMe drive, or diagnostic panel (optional)
(8) USB 3.0 connector (9) Compute module 2
