11-26
mLOM Ethernet adapters
In addition to mLOM Ethernet adapters, the server also supports PCIe Ethernet adapters (see "PCIe
Ethernet adapters").
By default, port 1 on an mLOM Ethernet adapter acts as an HDM shared network port.
NIC-GE-4P-360T-L3-M
Item Specifications
Form factor LP
Ports 4
Connector RJ-45
Data rate 1000 Mbps
Bus type 1000BASE-X ×4
NCSI Supported
NIC-10GE-2P-560T-L2-M
Item Specifications
Form factor LP
Ports 2
Connector RJ-45
Data rate 1/10 Gbps
Bus type 10G-KR ×2
NCSI Supported
NIC-10GE-2P-560F-L2-M
Item Specifications
Form factor LP
Ports 2
Connector SFP+
Data rate 10 Gbps
Bus type 10G-KR ×2
NCSI Supported
Riser cards
To expand the server with PCIe modules, install riser cards on the PCIe riser connectors or in riser
bays.
The PCIe slots in a riser card are numbered differently depending on the riser card model and the
PCIe riser connector or bay that holds the riser card.
