11-9
Fault/UID LED status Present/Active LED status Description
Steady amber
Steady green/Flashing green
(4.0 Hz)
The drive is faulty. Replace the drive
immediately.
Steady blue
Steady green/Flashing green
(4.0 Hz)
The drive is operating correctly and selected
by the RAID controller.
Off Flashing green (4.0 Hz)
The drive is performing a RAID migration or
rebuilding, or the system is reading or
writing data to the drive.
Off Steady green
The drive is present but no data is being
read or written to the drive.
Off Off The drive is not securely installed.
Drive configurations and numbering
The numbers of storage controllers in tables Table 11-6, Table 11-8, and Table 11-10 are applicable
to all storage controllers except for the RAID-LSI-9460-16i(4G). If you install the
RAID-LSI-9460-16i(4G), only one storage controller is required.
48SFF server
Table 11-6 presents the drive configurations available for the 48SFF server and their compatible
types of storage controllers and NVMe SSD expander modules. Table 11-7 sho
ws drive population
for the 48SFF server.
These drive configurations use the same drive numbering scheme, and drives with the same number
are distinguished by the compute module they reside in, as shown in Figure 11-3.
Table 11
-6 Drive, storage controller, and NVMe SSD expander configurations (48SFF server)
Drive configuration Storage controller NVMe SSD expander
48SFF (48 SFF SAS/SATA drives) 2 × storage controllers N/A
48SFF (24 SFF SAS/SATA drives) 1 × storage controller N/A
Table 11-7 Drive population (48SFF server)
Drive configuration Compute module 1 Compute module 2
48SFF
(48 SFF SAS/SATA drives)
24 SFF SAS/SATA drives 24 SFF SAS/SATA drives
24SFF
(24 SFF SAS/SATA drives)
24 SFF SAS/SATA drives N/A
NOTE:
"N/A" indicates that the compute module is not required but a compute module blank must be
installed.
