6-4
3. Install the drive. For more information, see "Installing SAS/SATA drives."
4. Install the removed security bezel. For more information, see "Installing the security bezel."
Verifying the installation
Use the following methods to verify that the drive is installed correctly:
• Observe the drive LEDs to verify that the drive is operating correctly. For more information, see
"Drive LEDs."
• Access the CLI or GUI of the server to verify the drive properties (including capacity) and state.
Installing power supplies
Guidelines
CAUTION:
To avoid hardware damage, do not use third-party power supplies.
• The power supplies are hot swappable.
• The server provides four power supply slots. Before powering on the server, install two to
achieve 1+1 redundancy, or install four power modules to achieve N+N redundancy.
• Make sure the installed power supplies are the same model. HDM will perform power supply
consistency check and generate an alarm if the power supply models are different.
• Install power supplies in power supply slots 1 through 4 in sequence.
Procedure
1. As shown in Figure 6-5, remove the power supply blank from the target power supply slot.
Figure 6-5 Removing the power supply blank
2. Align the power supply with the slot, making sure its fan is on the left.
3. Push the power supply into the slot until it snaps into place.
