Verifying the replacement
Log in to HDM to verify that the flash card and the supercapacitor are in a correct state. For more
information, see HDM online help.
Replacing a GPU module
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Replacing the GPU module in a compute module
The replacement procedure is the same for the GPU-P40-X, GPU-P100, and GPU-V100 GPU
modules. This section uses the GPU-P100 as an example.
To replace the GPU module in a compute module:
1. Power off the server. For more information, see "Powering off the server."
2. Remove the
security bezel, if any. For more information, see "Replacing the security bezel."
3. Remove the compute module. For more information, see "Removing a compute module."
4. Remove the compute module access panel. For more information, see "Replacing a compute
module a
ccess panel."
5. Remove the riser card in the compute module. Loosen the captive screw on the riser card, and
lift the riser card slowly out of the compute module, as shown in Figure 7-28.
Figure 7-28
Removing the riser card
6. Remove the GPU module from the riser card, as shown in Figure 7-29:
a. Hold and rotate the latch to the left to unlock the riser card, as shown by callout 1.
b. Disconnect the GPU power cord from the GPU module, as shown by callout 2.
c. Pull the GPU module out of the slot and then disconnect the GPU power cord from the riser
card, as shown by callouts 3 and 4.
