7-26
7. Reconnect the external cables to the riser card.
8. Connect the power cord. For more information, see "Connecting the power cord."
9. Powe
r on the server. For more information, see "Powering on the server."
Verifying the replacement
Log in to HDM to verify that the mLOM Ethernet adapter is in a correct state. For more information,
see HDM online help.
Replacing a PCIe Ethernet adapter
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Procedure
1. Power off the server. For more information, see "Powering off the server."
2. Disconnect external cables from the riser card that holds the PCIe Ethernet adapter.
3. Remove the riser card and the PCIe Ethernet adapter. For more information, see "Replacing a
rise
r card and PCIe module at the server rear."
4. Install a new PCIe Ethernet adapter. For more information, see "Installing a PCIe Ethernet
adapte
r."
5. If you have removed the riser card air baffle, install the removed riser card air baffle.. For more
information, see "Replacing a riser card air baffle."
6. Ins
tall the riser card to the server. For more information, see "Installing riser cards and PCIe
module
s at the server rear."
7. Reconnect the external cables to the riser card.
8. Connect the power cord. For more information, see "Connecting the power cord."
9. Powe
r on the server. For more information, see "Powering on the server."
Verifying the replacement
Log in to HDM to verify that the PCIe Ethernet adapter is in a correct state. For more information, see
HDM online help.
Replacing an M.2 transfer module and a PCIe M.2
SSD
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Replacing the M.2 transfer module and a PCIe M.2 SSD in a
compute module
1. Power off the server. For more information, see "Powering off the server."
2. Remove the security bezel, if any. For more information, see "Replacing the security bezel."
3. Remove the compute module. For more information, see "Removing a compute module."
