H3C UniServer R6900 G3 User Manual

11-40
LED Error code Faulty item
DIMM
A1 through A9,
AA, Ab, or AC
Compute module 1:
• A1 through A9—DIMMs in slots A1 through A9
• AA—DIMM in slot A10
• Ab—DIMM in slot A11
• AC—DIMM in slot A12
b1 through b9,
bA, bb, or bC
Compute module 1:
• b1 through b9—DIMMs in slots B1 through B9
• bA—DIMM in slot B10
• bb—DIMM in slot B11
• bC—DIMM in slot B12
C1 through C9,
CA, Cb, or CC
Compute module 2:
• C1 through C9—DIMMs in slots A1 through A9
• CA—DIMM in slot A10
• Cb—DIMM in slot A11
• CC—DIMM in slot A12
d1 through d9,
dA, db, or dC
Compute module 2:
• d1 through d9—DIMMs in slots B1 through B9
• dA—DIMM in slot B10
• db—DIMM in slot B11
• dC—DIMM in slot B12
HDD
00 through 23 Relevant drive in compute module 1 (24SFF)
30 through 53 Relevant drive in compute module 2 (24SFF)
00 through 07 Relevant drive in compute module 1 (8SFF)
10 through 17 Relevant drive in compute module 2 (8SFF)
PCIE
01 PCIe module in PCIe slot 1 of riser card 0 in compute module 1
03 PCIe module in PCIe slot 1 of riser card 0 in compute module 2
11 through 16 PCIe modules in PCIe slots 1 through 6 of riser card 1 at server rear
21 through 26 PCIe modules in PCIe slots 1 through 6 of riser card 2 at server rear
31 through 36 PCIe modules in PCIe slots 1 through 6 of riser card 3 at server rear
09
PCIe uplink between processors and the PCH for the mLOM Ethernet
adapter
PSU
01 Power supply 1
02 Power supply 2
03 Power supply 3
04 Power supply 4
FAN 01 through 06 Fan module 1 through Fan module 6
