Chapter 6: Receiver Configuration Modules Satellite Receiver Configuration
© Harmonic Inc. Manual p/n 101543/Ver 1.0 6-8 ProView 2900 Series/SW Version 1.94
Available LNB local oscilator types are:
• UNIVERSAL (9.75,10.6) – Selects LNB universal L.O. type
• WIDE BAND (9.75, 10.75) – Selects LNB wide band L.O. type
• Ku-BAND – Defines Ku-Band LNB L.O. type
• C-BAND – Defines C-Band LNB L.O. type
• DiSEqC (9.75, 10.75) – Selects DiSEqC LNB L.O. type
NOTE
When selecting the Ku-Band or the C-Band local oscilator, you must manually set the L.O.
frequency (see the LNB L.O. Frequency configuration function detailed in paragraph 6.2.1.9).
6.2.1.9. LNB L.O. Frequency
The LNB L.O. Frequency configuration parameter sets the fixed LNB oscillator frequency for
the Ku or C-Band L.O. in the LNB.
The following figure illustrates the Ku-Band Frequency screen.
LNB L.O.
LNB L.O. LNB L.O.
LNB L.O. Frequency
Frequency Frequency
Frequency
1.
1.1.
1. 9750
9750 9750
9750000 [
000 [000 [
000 [k
kk
kHz]
Hz]Hz]
Hz]
<
<<
<850
850850
8500000
0000 0000
0000 -
--
- 1300
13001300
13000000>
0000>0000>
0000>
Available frequency range is:
• For Ku-Band L.O.: 8500000 to 13000000 [KHz]
• For C-Band L.O.: 5000000 to 6000000 [KHz]
6.2.1.10. Frequency Range
The Frequency Range parameter defines the input frequency in the Ku, C or L bands.
This parameter affects the displayed frequencies and ranges of the ProView 2900 DVB-S
receiver parameters. The following figure illustrates the Frequency Range screen.
Frequency Range
Frequency Range Frequency Range
Frequency Range
1
11
1

 L BAND
L BAND L BAND
L BAND
2
22
2

 Ku BAND
Ku BAND Ku BAND
Ku BAND
3
33
3

 C BAND
C BAND C BAND
C BAND
Available frequency band options are:
• L BAND – selects the frequency range 0.950000 - 2.150000 GHz
• Ku BAND - selects the frequency range 3.200000 - 4.200000 GHz
• C BAND - selects the frequency range 10.700000 - 12.750000 GHz
