Touch probe cycles | Circular measurement
5
HEIDENHAIN | User's Manual smart.Turn and DIN Programming | 12/2017
559
F: Measuring feed – feed rate for probing (if nothing is entered,
the measuring feed rate from the touch probe table is used)
If the entered measuring feed rate F is higher than the one in
the touch probe table, the feed rate is reduced to the value from
the touch probe table.
NF: Variable no. result – number of the first global variable in
which the result is saved (no input: Variable 810)
The second measurement result is saved automatically to the
next consecutive number.
P: PRINT outputs
0: OFF – do not display measuring results
1: ON – display measuring results on the screen
H: INPUT instead of measure
0: Standard – obtain measured values by probing
1: PC test – simulate touch probe cycle on the programming
station
AN: Log no. – save measurement results in the
TNC:\table\messpro.mep table (line numbers 0-99)
The table can be expanded if necessary.
Example: G786 Calculation of pitch circle
. . .
MACHINING
N3 G786 R0 K8 I0 J0 D50 WS50.1 WC49.9BD0.1 BE0.1 P0
H0
. . .
