Overview of G commands in the
CONTOUR section
G commands for turning contours
Workpiece-blank definition Page
G20-Geo Chuck part cyl./tube
Page 245
G21-Geo Cast part
Page 245
Basic contour elements Page
G0-Geo Starting point
Page 246
G1-Geo Distance
Page 247
G2-Geo Circular arc cw
Page 249
G3-Geo Circular arc ccw
Page 249
G12-Geo Circ. arc. abs. ccw
Page 251
G13-Geo Circ. arc. abs. ccw
Page 251
Contour form elements Page
G22-Geo Recess (standard)
Page 253
G23-Geo Recess (general)
Page 255
G24-Geo Thread with undercut
Page 257
G25-Geo Undercut
Page 258
G34-Geo Thread (standard)
Page 261
G37-Geo Thread (general)
Page 262
G49-Geo Bore hole (centric)
Page 265
Help commands for contour definition Page
Overview: Attributes for contour description Page 266
G38-Geo Feed rate reduction
Page 266
G44 Separation point
Page 268
G52-Geo Contour-parallel oversize
Page 268
G95-Geo Feed per rotation
Page 269
G149-Geo Additive correction
Page 270
