TURN PLUS | Full-surface machining with TURN PLUS
7
652
HEIDENHAIN | User's Manual smart.Turn and DIN Programming | 12/2017
Example of second setup for full-surface machining
Parameters:
No. of clamping H: CHUCKING EQUIPMENT 2
Spindle number AWG D:
0: Main spindle
3: Opposing spindle (depending on type of rechucking)
Clamp type R:
0: J=Free length
1: J=Fixing length
Edge of chuck Z: no input (AWG uses the value from the user
parameters)
Chuck jaw reference B: no input (AWG uses the value from
the user parameters)
Clamping length or Unclamping length J: Enter the clamping
length or free length
Cutting limit, outside O: is calculated by AWG (if external
clamping is used)
Cutting limit, inside I: is calculated by AWG (if internal clamping
is used)
Overlap jaw/workpiece K: overlap of jaw/workpiece
Chuck diameter X: clamping diameter of workpiece blank
Chuck form Q:
5: Outside chucking
5: Inside chucking
Shaft machining AWG V: Select the desired AWG strategy
Example: Defining the second chucking equipment
...
CHUCKING EQUIPMENT 2
H0 D3 R1 J15 K-15 X68 Q4 V0
...
