Content Management Application (CMA)
DML-1200 w/Axon Embedded Graphic Engine 24/12/2010 _____________________________________________________________________________ 106
6.3.2.3 Media Files
Inside
User Image
and
Stock Image
folders are Library folders containing collections of media files. Media files can be still images
or video clips in one of the following formats:
The stock media files provided by High End Systems have been compressed and optimized for reliable and smooth playback from
media servers. Each file and folder has an associated DMX value. These values are fixed for Stock Content but must be assigned for
all user created content. See
Assigning DMX Values to User Content
on page 103 for more information.
6.3.2.4 Object Files
Object files are the 3-D object component files used to build a graphic image. The Digital Media Server DMX protocol supports a
combined total of 255 object files displayed in
Stock Objects
and
User Objects
folders. As with
Stock Media
files, the
Stock Objects
have a fixed DMX value and cannot be edited. A user-created object file must be assigned a unique DMX value between 150-255.
6.3.3 Viewing Server Configuration Data
Selecting an individual server from the list in the left pane displays all the configuration values for that server in the right pane.
Selecting
All Configuration
displays the combined configuration values for all the servers on the network. For more information on
server configuration, see
Viewing Server Configuration
on page 113.
.jpg
.gif .png .bmp .mpv .m1v .mpg .m2v
Axon and Digital Light media servers supports .jpg formatted using RGB color. CMYK color files are not currently
supported.
Mac OS X: Viewing Server Configuration
To access Server Configuration information for an individual server, select the Configuration option under the
individual server.
