High End Systems DML-1200 - Collage Generator; Enhanced Collage Generator; Collage Gen 3; Collage Generator Wrap

Effect Mode Options Descriptions
75 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
5.2.3 Collage Generator
Collage Generator effects let you use multiple digital lighting fixtures projectors controlled with an Axon Media server to create
virtually seamless panoramic media projections with DMX control. You can display either stock (automated collage) or custom
content (segmented collage) and effects are available for full 360° projection. For more information about this global effect, (see
Global Functions on page 32.
Modifier 1: Selects which type of Collage array to use from DMX Values 1-63. A DMX value of 0 = No Collage. DMX Values of 64-255
are reserved and default to No Collage.
Modifier 2: Selects which portion of the grid a particular device will display. DMX values 0-63 step through grid pattern selected by
the Modifier 1 parameter. DMX values 64-255 default to the upper left corner of the grid.
Modifier 3: Adjusts edge blending between the selected portion of the image being projected by the fixture and adjacent portions
being projected by other fixtures.
5.2.3.1 Collage Generator
Effect Mode parameter DMX value = 134
The standard
Collage Generator was the original automated collage effect and should only be used with legacy shows.
5.2.3.2 Enhanced Collage Generator
Effect Mode parameter DMX value = 141
This automated collage effect improves the image resolution over the initial Collage Generator.
5.2.3.3 Collage Gen 3
Effect Mode parameter DMX value = 150
Collage Gen 3 effect has the image resolution of the Enhanced Collage Generator effect and further expands and improves the
edge blending control.
5.2.3.4 Collage Generator Wrap
Effect Mode parameter DMX value = 145
The
Collage Generator Wrap effect adds right and left edge blending to create 360° panoramas.
5.2.3.5 Collage Gen 3 Wrap
Effect Mode parameter value = 151
This effect expands and enhances edge blending controls of effect 145.
5.2.3.6 Segmented Collage Generator
Effect Mode parameter DMX value = 146
The
Segmented Collage Generator effect accepts user defined portion of content for each cell in the grid.
5.2.3.7 Segmented Collage Gen 3
Effect Mode parameter DMX value = 152
The
Segmented Collage Gen 3 effect accepts user defined portion of content for each cell in the grid with expanded and improved
edge blending control to effect 146.
5.2.3.8 Segmented Collage Generator Wrap
Effect Mode parameter DMX value = 147
The
Segmented Collage Wrap effect adds right and left edge blending to the user defined cell content to create 360° panoramas.
5.2.3.9 Segmented Collage Gen 3 Wrap
Effect Mode parameter DMX value = 153
The
Segmented Collage Gen 3 Wrap effect adds right and left edge blending to the user defined cell content to create 360°
panoramas with expanded and improved edge blending control over effect 147.
Automated Collage Generator Options Segmented Collage Generator Options
Flat Collage 360° Wrap Flat Collage 360° Wrap
Global Effect DMX Value
134
141 145 146 147
150 151 152 153
Object Effect Global Effect
