122 _____________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
A.1.3 Global Control
A.1.4 Axon Graphic Object Control
Parameter Name DMX Chan # Parameter Name DMX Chan #
Global Intensity 38 Keystone Top Left X 66
Global Effect 1 39 Keystone Top Left Y 67
Global Effect 1 Modifier 1 40 Keystone Top Right X 68
Global Effect 1 Modifier 2 41 Keystone Top Right Y 69
Global Effect 1 Modifier 3 42 Keystone Bottom Right X 70
Global Effect 2 43 Keystone Bottom Right Y 71
Global Effect 2 Modifier 1 44 Keystone Bottom Left X 72
Global Effect 2 Modifier 2 45 Keystone Bottom Left Y 73
Global Effect 2 Modifier 3 46 Keystone X Ratio 74
Global Effect 3 47 Keystone Y Ratio 75
Global Effect 3 Modifier 1 48 Framing Top Left X 76
Global Effect 3 Modifier 2 49 Framing Top Left Y 77
Global Effect 3 Modifier 3 50 Framing Top Right X 78
Global Effect 4 51 Framing Top Right Y 79
Global Effect 4 Modifier 1 52 Framing Bottom Right X 80
Global Effect 4 Modifier 2 53 Framing Bottom Right Y 81
Global Effect 4 Modifier 3 54 Framing Bottom Left X 82
Global Effect 5 55 Framing Bottom Left Y 83
Global Effect 5 Modifier 1 56 Viewpoint mode 84
Global Effect 5 Modifier 2 57
Viewpoint Position X
85
Global Effect 5 Modifier 3 58 86
Mask Select (default iris) 59
Viewpoint Position Y
87
Mask Size 60 88
Mask Edge 61
VIewpoint Position Z
89
Edge Fade Top 62 90
Edge Fade Right 63 Global Control 91
Edge Fade Bottom 64 Global Control Modifier 92
Edge Fade Left 65
Parameter Name
DMX Channel #
Obj.1 Obj.2 Obj.3 Obj.4 Obj.5 Obj.6 Obj.7 Obj.8 Obj.9
Opacity 93 138 183 228 273 318 363 408 453
3-D Object File 94 139 184 229 274 319 364 409 454
Media Folder 95 140 185 230 275 320 365 410 455
Media File 96 141 186 231 276 321 366 411 456
In Frame
97 142 187 232 277 322 367 412 457
98 143 188 233 278 323 368 413 458
Out Frame
99 144 189 234 279 324 369 414 459
100 145 190 235 280 325 370 415 460
Play Mode 101 146 191 236 281 326 371 416 461
Play Speed 102 147 192 237 282 327 372 417 462
Sync Type 103 148 193 238 283 328 373 418 463
Sync To 104 149 194 239 284 329 374 419 464
Visual Mode 105 150 195 240 285 330 375 420 465
Visual Mode Modifier 1 106 151 196 241 286 331 376 421 466
Visual Mode Modifier 2 107 152 197 242 287 332 377 422 467
Graphic Effect 1 108 153 198 243 288 333 378 423 468
Effect 1 Modifier 1 109 154 199 244 289 334 379 424 469
Effect 1 Modifier 2 110 155 200 245 290 335 380 425 470
Effect 1 Modifier 3 111 156 201 246 291 336 381 426 471
Graphic Effect 2 112 157 202 247 292 337 382 427 472
Effect 2 Modifier 1 113 158 203 248 293 338 383 428 473
Effect 2 Modifier 2 114 159 204 249 294 339 384 429 474
Effect 2 Modifier 3 115 160 205 250 295 340 385 430 475
