Global Functions
49 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
4.12.1.2 User Segmented Collage Options
In situations where you require extremely high resolution output of custom content, you can select the
Segmented Collage
Generator
option (DMX value = 146). Segmented Collage Generator options operate like automated collage option except that
content is not automatically divided into cells by the graphics engine. Instead, you configure your collage content for the fixtures
before loading it into the server.
Once projected, Segmented Collage options’ resolution capabilities are increased many times over that of the automated collage
options because the graphics engine is no longer taking a single file and stretching it across multiple servers; but is, instead,
showing the file as rendered. Using Segmented Collage options, you can project a 1024x768 file from each server. In addition to
the higher resolution, there is less strain on the server since it is not playing back the very large file that would be required with
the automated options to get the same high resolution.
Just as with the Enhanced Collage Wrap, the
Segmented Collage Generator Wrap
option (DMX value = 147) adds right and left edge
blending to the user defined cell content for 360 degree panoramas. The
Segmented Collage Gen 3 Wrap
(DMX value = 153)
provides improved edge blending.
For more information on developing Segmented Collage content, refer to the Digital Lighting pages at www.highend.com
.
4.12.2 Adjusting the Collage Array with Global Modifier Parameters
The three
Global
Effects Mode Modifier
parameters operate as follows:
The
Modifier 1
parameter selects which type of Collage array to use from DMX Values 1-127. The selected size displays in the
upper right corner of the grid pattern. A DMX value of 0 = No collage. DMX Values of 126-255 are reserved and defaults to No
collage.
The Segmented Collage options only work on 3-D Object #1, which is the 4x3 default rectangle. Custom
segmented content will not line up correctly when used on other 3-D objects. If you select a 3-D object other than
Object #1, the server will automatically go back to running in Enhanced Collage mode.
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
DMX
Value
Array
(W x H)
1 2 x 1261 x 6518 x 27610 x 510113 x 6
2 1 x 2276 x 2522 x 87710 x 610213 x 7
3 2 x 2282 x 6538 x 37810 x 710313 x 8
4 3 x 1296 x 3543 x 87910 x 810414 x 1
5 1 x 3303 x 6558 x 48011 x 110514 x 2
6 3 x 2316 x 4564 x 88111 x 210614 x 3
7 2 x 3324 x 6578 x 58211 x 310714 x 4
8 3 x 3336 x 5585 x 88311 x 410814 x 5
9 4 x 1345 x 6598 x 68411 x 510914 x 6
101 x 4356 x 6606 x 88511 x 611014 x 7
114 x 2367 x 1618 x 78611 x 711114 x 8
122 x 4371 x 7627 x 88711 x 811215 x 1
134 x 3387 x 2638 x 88812 x 111315 x 2
143 x 4392 x 7649 x 18912 x 211415 x 3
154 x 4407 x 3659 x 29012 x 311515 x 4
165 x 1413 x 7669 x 39112 x 411615 x 5
171 x 5427 x 4679 x 49212 x 511715 x 6
185 x 2434 x 7689 x 59312 x 611815 x 7
192 x 5447 x 5699 x 69412 x 711915 x 8
205 x 3455 x 7709 x 79512 x 812016 x 1
213 x 5467 x 6719 x 89613 x 112116 x 2
22 5 x 4 47 6 x 7 72 10 x 1 97 13 x 2 122 16 x 3
23 4 x 5 48 7 x 7 73 10 x 2 98 13 x 3 123 16 x 4
24 5 x 5 49 8 x 1 74 10 x 3 99 13 x 4 124 16 x 5
25 6 x 1 50 1 x 8 75 10 x 4 100 13 x 5 125 16 x 6
126 16 x 7
127 16 x 8
