Content Management Application (CMA)
123 _____________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
6.11.2 Display Settings Tab
Graphics Output Display Settings
Projector Settings
Self Tests
Configuration Item Configuration Value Options
Resolution
Options in the drop-down lists are automatically populated by the Axon software for the specific
display device attached.
Refresh Rates
Color
Configuration Item Configuration Value Options
Output Device Read Only displays projector model
Configuration Item Configuration Value Options
Video Pattern
1 displays graphic object with texture for the number of graphic layers you have defined
2 alternates between an alignment grid and a color calibration screen
