2.2.4.3 Z Position
The Z Position parameter moves your object along the Z axis with 16-bit precision.
The midpoint of the 16-bit DMX value range centers the object on the Z axis. Values below the DMX midpoint move the object
away from the viewer and appears to become smaller, and object above the DMX midpoint move the object toward the viewer
and appears to become larger.
Default DMX Value: 32768 (50%) = object centered in frame
This parameter can create a zoom effect. Remember that by moving an object, you can obscure other objects or
move it behind your viewpoint where it is no longer visible.
Original Object 1 and Object 2
All Position DMX values = 32768 (50%)
Object 1: Z Position DMX value = 32822
Object 1: Z Position DMX value = 31884
Object 1: Z Position DMX value = 33144
