High End Systems DML-1200 - Solid Color RGB; Transparent Color; Transparent Color Coarse; Transparent Color Fine

Effect Mode Options Descriptions
71 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
5.1.38 Solid Color RGB
Effect Mode parameter DMX value = 16
Solid Color RGB removes the media file texture and allows you to color mix the 3-D object to one solid color
Modifier 1: Increases red color component from 0 = no adjustment to 255 (100%) = maximum red saturation.
Modifier 2: Increases green color component from 0 = no adjustment to 255 (100%) = maximum green saturation.
Modifier 3: Increases blue color component from 0 = no adjustment to 255 (100%) = maximum blue saturation.
5.1.39 Transparent Color
These effects remove a color (or small color range) from one graphic image to reveal another “behind” it. The removed color
becomes transparent. Modifier parameters define the color you want to select as the transparent color in terms of Red, Green and
Blue values set in the Modifier parameters.
Modifier 1: Defines the red color component from DMX values of 0 = no red to 255 (100%) = maximum red saturation.
Modifier 2: Defines the green color component from DMX values of 0 = no green to 255 (100%) = maximum green saturation.
Modifier 3: Defines the blue color component from DMX values of 0 = no blue to 255 (100%) = maximum blue saturation.
5.1.39.1 Transparent Color Coarse
Effect Mode parameter DMX value = 28
The Transparent Color Coarse parameter selects a color range ±40% either side of the defined value.
5.1.39.2 Transparent Color Fine
Effect Mode parameter DMX value = 26
The Transparent Color Fine parameter selects a color range ±15% either side of the defined value.
5.1.39.3 Transparent Color Medium
Effect Mode parameter DMX value = 27
The Transparent Color Medium parameter selects a color range ±25% either side of the defined value.
5.1.40 Transparent Color, Invert
These effects remove a color (or small color range) from one graphic image to reveal another “behind” it. An Inverted Transparent
Color effect selects a color range either side of the defined value and then sets every other color as transparent.
Modifier 1: Defines the red color component from 0 = no red to 255 (100%) = maximum red saturation.
Modifier 2: Defines the green color component from 0 = no green to 255 (100%) = maximum green saturation.
Modifier 3: Defines the blue color component from 0 = no blue to 255 (100%) = maximum blue saturation.
5.1.40.1 Transparent Color Invert, Coarse
Effect Mode parameter DMX value = 31
The Transparent Color Invert, Coarse effect selects a color range ±40% either side of the defined value.
5.1.40.2 Transparent Color Invert, Medium
Effect Mode parameter DMX value = 30
The Transparent Color Invert, Medium effect selects a color range ±25% either side of the defined value.
5.1.40.3 Transparent Color Invert, Fine
Effect Mode parameter DMX value = 29
The Transparent Color Invert, Fine effect selects a color range ±15% either side of the defined value.
Object Effect Global Effect
Object Effect Global EffectObject Effect Global Effect
Object Effect Global Effect
