Graphic Functions
21 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
2.3.3 Visual Mode Options
2.3.3.1 Color to B/W
Visual Mode
Parameter DMX value = 7
Begins with a white screen and fades to the original image in black and white. All color is converted.
Modifier 1:
Transitions the image from full white at a DMX value of 0 to black and white at a value of 128 (50%). Increasing values
above 50% reveals more of the image in black and white to complete at a value of 255 (100%).
Modifier 2:
Not Used
9 Negative Art
Reverses image color
Scales color
Subtract red to
Subtract Green
10 Exposure Control
Alternate content optimization option
Expand/Contrast
Color
Adjusts
color shift
11 Invert B/W
Inverts Black and White components. Color remains unaffected
Sets Black
Comparison Level
Sets White
Comparison Level
12
Texture
Mixing
Crossfades between the current image and another graphic object
texture.
Selects Source
Object Texture
Controls
Crossfade
13
Image Scale
and Rotate
Scales and rotates the media file texture applied to a 3-D object
Scales Image
Sets
Rotation Angle
14 Film Roll
Scrolls the media file texture horizontally or vertically
Sets Horizontal Roll
Speed
Sets Vertical
Roll Speed
15 Pixelate
Divides the image into rectangles using the center pixel color of
each “box” as its color
Adjusts amount of
pixelation
Not Used
16 Faux LED
Divides the image into a grid of circles to mimic an LED wall
Varies grid from
100x100 to 10x10
Varies spacing
and B/W
17 Faux Tile
Divides the image into square tiles
Varies grid from
100x100 to 10x10
Varies spacing
and B/W
18 Fuzzifier
Creates a multi-image blurring effect
Horizontal
fuzz distance
Vertical
fuzz distance
19 Drop Shadow
Creates a scalable drop shadow behind the graphic object
Horizontal
shadow size
Vertical
shadow size
20 Zoom Blur
Zooms into a position on the image with a mult-image blurring effect
Sets horizontal
position
center
Sets vertical
position center
21 Chroma Shift
Shifts the red, blue, and green component colors
Horizontal shift Vertical shift
22 ShakeNBake
Introduces a random vibration effect
Horizontal shake Vertical shake
23 CTO/CTB
Color temperature correction
Push to Orange Push to Blue
24 Flip
Flips layer content
Horizontal flip Vertical flip
255 Pan and Scan
Zooms in and pans across a still image
Horizontal position Vertical position
Visual Mode Option Adjustments
DMX
Value
Name Description Modifier 1 Modifier 2
