Graphic Functions
11 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
2.1.3.1 Object
The
Object
parameter selects the 3-dimensional object component of an image. Object files are the 3-D object shapes used to build
a total image. The graphics engine supports a combined total of 255 stock and user-created object files.
Stock Objects have a fixed DMX value and cannot be edited. DMX values 1-149 are reserved for identifying stock object files. User-
created object files must be assigned a unique DMX value from 150-255.
For a reference of 3-D object files available as stock content with your media server and information on how to create your own
object files, go to the link for the Stock Object Guide for digital lighting products on http://www.highend.com/support/
digital_lighting/.
Default DMX Value:
1 = full screen flat surface
2.1.3.2 Media Folder
This parameter defines a folder (directory) containing a collection of media files. The media files within the assigned folder can
then be selected using the
Media File
parameter. DMX values for folders are assigned as follows:
• DMX values = 1-39 are used or reserved for Stock Content
• DMX values = 40-240 are reserved for User Content
• DMX value = 255 is reserved for live video input
Default DMX Value :
1 (HES Core Media files)
The following table describes the Stock Content folders available on DML-1200 w/Axon media servers.
Media Folder Descriptions
You can select the same object file for images that will be interacting with each other. If both objects occupy
exactly the same area in 3-D space, “Z-fighting” (a shimmering effect) on some portions of the composite image
can occur as the graphics engine tries to determine which object should be in the foreground. You can avoid this
effect by making a slight adjustment to one of the object’s scale or moving it forward or back (using the Z Position
parameter) in respect to the other.
Value Media Folder Name Content Description
1
HES Core Premier High End Systems video loop collection
2
HES_Digital_Aerials_1 Digital still images and animations, designed for aerial effects
3
HES_Oils Digitally simulated psychedelic oil projection loops
4
HES_Atmospheric Video loops of natural settings clouds, water, fire
5
On_The_Wall_Studios Digital video loops, promotional
6
Sean_Bridwell Digital video loops, promotional
7
A_Luna_Blue Digital video loops, promotional
8
Feedback_Video Digital video loops, promotional
9
HES_Texture Video loop textures
10
HES_Foliage Collection of abstract and realistic foliage and floral video loops
11
HES_Religious Religious themed video loops
12
HES_Gothic Set of themed video loops
13
HES_Digital_Aerials _2 Digital still images and animations, designed for aerial effects
14
HES_Theme_Stills Nature stills (foliage and flowers)
15
Apollo Glass Digital Gobo Patterns, promotional
16
Artbeats Digital video loops, promotional
17
DHA_TopMac Digital patterns, promotional
18
Beacon DigiGobos Digital video loops, promotional
19
Amorphous Digi-gobos Digital animations, promotional
20
InLight Digital video loops, promotional
21
HES_Lithopatterns_1 High End Systems Lithopattern® images
22
HES_Lithopatterns_2 More images from High End Systems Lithopattern library
23
HES_Logos High End Systems® Axon and DL.2™ logos
24
HES_Hi_Res Variety of high resolution video backgrounds
25
NASA_Images Space images from the Hubble telescope
