APPENDIX A:
DML-1200 w/AXON DMX PROTOCOL
A.1 DMX CHANNEL ASSIGNMENT FOR DML-1200 w/AXON
The following tables list the parameters for the Embedded Graphics Engine and their associated DMX channel number(s). The range
for a server on the DMX link depends on the number of Graphic Objects you select for your application. For more detailed
information on DMX Protocol, please contact customer support at High End Systems.
A.1.1 Motion Control
A.1.2 Image Control
Blue shaded parameters are not available in Version 1 Protocol
You can find more detailed information about the Motion Control and Image Control Parameters in the
DML-1200 User Manual on the High End Systems website and the CD shipped with your fixture.
Parameter Name DMX Chan #
Pan Coarse 1
Pan Fine 2
Tilt Coarse 3
Tilt Fine 4
Intensity 5
Optical Zoom 6
Focus 7
Shutter 8
Cyan 9
Magenta 10
Yellow 11
CTO 12
Mode Selection 13
Iris 14
Control 15
Parameter Name DMX Chan #
Source Selection 16
Brightness 17
Contrast 18
Saturation 19
Orientation 20
Blanking, left coarse 21
Blanking, left fine 22
Blanking, right coarse 23
Blanking, right fine 24
Blanking, top coarse 25
Blanking, top fine 26
Blanking, bottom coarse 27
Blanking,bottom fine 28
Soft edge left 29
Soft edge right 30
Soft edge top 31
Soft edge bottom 32
Reserved 33-35
Warp 36
Reserved 37
