Global Functions
41 ______________________________________________________DML-1200 w/Axon Embedded Graphic Engine 24/12/2010
4.3 Global Control
The Global Control parameter allows access to different global control modes. How you set the Global control parameter
determines the functionality of the
Global Control Modifier parameter. Setting this parameter to a DMX value of 255 brings up On-
screen programming statistics. In this case, the
Global Control Modifier parameter controls the text color.
4.3.1 Shutdown and Reset Options
When the Global Intensity parameter is set to 0, you can Shutdown the server (DMX Value = 120-130) or Reset the internal
Graphics Engine for DML w/Axon media servers (DMX Value = 145-149).
4.3.2 On-Screen Statistics
4.3.2.1 Spherical Control Statistics
When the Global Control parameter is set to a DMX value = 252, Spherical Control Statistics are displayed and the Global Control
Modifier
parameter selects text color. page 324.
4.3.2.2 Performance Statistics
When the Global Control parameter DMX value = 254, performance statistics are projected on screen. These are a subset of the
statistics shown when
Global Control = 255.
Statistics displayed are:
• render loops per second
• CPU utilization
• hard disk read
• cue length
• available memory
The
Global Control Modifier controls the opacity of the of the statistics display background, fading from 0 = opaque to 255 =
transparent.
4.3.2.3 Text Color
When the Global Control parameter is set at a DMX Value of 255, the Global Control Modifier parameter lets you choose the text
color that will best display over your selected image:
150
Collage Gen 3 provides, updated blend curves for large collage
arrays
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
151
Collage Gen 3 Wrap provides updated right and left blend curves for
360° panoramas
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
152
Segmented Collage Gen 3, improved blending over global effect 146.
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
153
Segmented Collage Gen 3 Wrap, improves edge blending over
global effect 147.
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
223
Modifier used with global spherical mapping effect 142. Defaults to 0
otherwise.
NA NA NA
224
Modifier used with global spherical mapping effect 142. Defaults to 0
otherwise.
NA NA NA
255
Pan and Scale zooms in and pans across a still image
Horizontal position
Vertical
position
Zoom in
and out
DMX Value Color
1Gray
2Red
3Blue
4Green
DMX
Value
Effect Mode Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
