Global Functions
DML-1200 w/Axon Embedded Graphic Engine 24/12/2010 _____________________________________________________________________________ 40
93
Film Burn/Unburn create a burn pattern on the image
Burn/Unburn Rate Film Blackening
Burn
Pattern
94
Film Noise creates an “aged” film effect
Noise Rate
Push to Sepia
add Jitter
Noise Level
95
Particle System 1 converts image to a particle pattern
Emitter Type Trail Length Particle Acceleration
96
Particle System 2 adds adjustments to Effect 95
Number of Particles Particle Size Emitter Size
97
Particle System 3 adds adjustments to Effect 95 + Effect 96
Initial Particle
Velocity
Particle
Rotation
Particle
Lifetime
98
Prism
Number of Facets Refraction Index Rotation
99
Gaussian Halo creates blur from clear center toward the edges of an
Sample
Distance
Number of
Filter Passes
Gaussian
Curve Shape
100
Scene Change Detect transparency effect
Scale RGB RGB to Alpha
Scale color with
alpha applied
101
Yxy Luminance Scaling adjusts brightness without effecting color
Scale Luminance Scale X Scale
102
Prerotation Translation places object in 3-D space
Translate X Translate Y Translate Z
103
Digital Mspeed.
Rotation MSpeed Scaling MSpeed Position MSpeed
128
Mask Color applies color to mask parameter selection
Red Green Blue
129
Edge Fade Color applies color to Edge Fade parameter selection
Red Green Blue
130
Mask Color and Edge Fade Color applies the same color to both the
selected Mask and Image Edge Fade parameters
Red Green Blue
131
Background Color selects background color
Red Green Blue
132
Background Color Cycle sequences the background color
Red Speed Green Speed Blue Speed
133
Edge Fade Profiles defines edge fading patterns
Selects Mode Adjusts Profile Selects Source
134
Collage Generator creates multi-fixture panorama displays, (see
Collage Generator™ Effect on page 43).
Selects Array Type
Selects array cell
for display
Adjusts Edge
blending
135
Curve Correction, Vertical Convex Cylinder corrects shape projecting
on curved surface
Adjusts Correction Sets Vertical Center Not Used
136
Curve Correction, Vertical Concave Cylinder corrects shape
projecting on curved surface
Adjusts Correction Sets Vertical Center Not Used
137
Curve Correction, Vertical Inside Corner corrects shape projecting on
curved surface
Adjusts Correction Sets Vertical Center
Sets Horizontal
Center
138
Curve Correction, Vertical Outside Corner corrects shape projecting
on curved surface
Adjusts Correction Sets Vertical Center
Sets Horizontal
Center
139
Curve Correction, Outside Sphere corrects shape projecting on a
sphere’s outside surface
Adjusts Correction Sets Vertical Center
Sets Horizontal
Center
140
Curve Correction, Inside Sphere corrects shape projecting on a
sphere’s inside surface
Adjusts Correction Sets Vertical Center
Sets Horizontal
Center
141
Enhanced Collage Generator provides higher resolution for collage
arrays larger than 4 x 4.
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
142
Spherical Mapping, Outside maps output to a portion of a sphere’s
outside surface.
Sets Longitude
Angle
Sets Latitude
Angle
Sets Latitude
Center
143
Spherical Mapping, Inside maps output to a portion of a sphere’s
inside surface.
Sets Longitude
Angle
Sets Latitude
Angle
Sets Latitude
144
Mattes apply provided mattes over image
Matte Effect Matte Pattern Texture Source
145
Collage Generator Wrap adds right and left edge blending for 360
degree panoramas
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
146
Segmented Collage Generator accepts user defined portion of
content for each cell in the grid
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
147
Segmented Collage Generator Wrap adds right and left edge
blending to the user defined cell content for 360° panoramas
Selects Array Type
Selects array
cell to display
Adjusts Edge
blending
148
Curved Surface, Horizontal Convex Cylinder
corrects shape projecting on curved surface
Adjusts Correction
Sets Horizontal
Center
Not Used
149
Curved Surface, Horizontal Concave Cylinder corrects shape
projecting on curved surface
Adjusts Correction
Sets Horizontal
Center
Not Used
DMX
Value
Effect Mode Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
