High End Systems DML-1200 - Pan and Scan

Effect Mode Options Descriptions
DML-1200 w/Axon Embedded Graphic Engine 24/12/2010 _____________________________________________________________________________ 88
Modifier 3: This parameter determines the texture for the Matte mode selected with the Modifier 1 parameter.
5.2.24 Pan and Scan
Effect Mode parameter DMX value = 255
This effect Zooms into a still image and then, by changing position, you can pan across the image horizontally and vertically. It
only functions on image sizes greater than 1024 x 1024 in at least one direction.
Modifier 1: Adjusts the horizontal pan position from 0=left edge to 255 (100%) = right edge of the image. The default DMX value of
128 (50%) = no adjustment.
Modifier 2: Adjusts the vertical pan position from 0 = bottom edge to 255 (100%) = top edge of the image. The default DMX value
of 128 (50%) = no adjustment.
Modifier 3: The default DMX value is 0 = no zoom. Increasing the value, increases the zoom into the image to a maximum at a
value of 255 (100%). The total Zoom range is proportional to the image size.
Modifier 1
DMX Value
Modifier 3
DMX value Action
0 - 3 NA
Not Used
4 - 9
0
Graphic Object 1 texture without applied Effects
1
Graphic Object 1 texture including its first applied Effect
2
Graphic Object 1 texture including its first two applied Effects
3
Graphic Object 1 texture including its first three applied Effects
10
Graphic Object 2 texture without applied Effects
11
Graphic Object 2 texture including its first applied Effect
12
Graphic Object 2 texture including its first two applied Effects
13
Graphic Object 2 texture including its first three applied Effects
20
Graphic Object 3 texture without applied Effects
21
Graphic Object 3 texture including its first applied Effect
22
Graphic Object 3 texture including its first two applied Effects
23
Graphic Object 3 texture including its first three applied Effects
10 - 11 0-255
Color selected as a look up value from an internal gradient.
Although you can apply this effect in several different modes (global, graphic and visual), the modifier channel
adjustments will only function if there is enough “room” left on the image to move. In most cases the first
application of this effect will be the only one to have an effect.
Object Effect Global Effect
