Firewall
296
8.3
The BAT Firewall
BAT54-Rail/F..
Release
7.54
06/08
If you call up the logging table via LANmonitor, it looks like the following de-
piction:
If you call up the logging table via WEBconfig, it looks like the following de-
piction:
The table contains the following values:
Element Element meaning
Idx. Current index (so that the table can be polled also via SNMP)
System time System time in UTC codification (will be transformed on displaying of the table into clear
text)
Src address Source address of the filtered packet
Dst address Destination address of the filtered packet
Prot. Protocol (TCP, UDP etc.) of the filtered packet
Src-p Source port of the filtered packet (only with port-related protocols)
Dst-p Destination port of the filtered packet (only with port-related protocols)
Filter-Rule Name of the rule, which has raised the entry.
