The BAT Firewall
297
Note: All Firewall actions are likewise displayed within the IP router trace
(’How to start a trace’ → page 225). Furthermore, some BAT models have
a Firewall LED, which signals each filtered packet.
U The filter list
The filter list allows to examine filters generated by rules defined in the action,
object and rule table.
Note: Please note that manually entered filter rules do not generate a fault
indication and also no error message. If you configure filters manually,
you should in each case examine on the basis of the filter list whether the
desired filters were generated or not.
On Telnet level, the content of the filter list can be displayed with the com-
mand
show filter
:
Limit Bit field, which describes the crossed limit, which has filtered the packet. The following
values are defined at present:
0x01 Absolute number
0x02 Number per second
0x04 Number per minute
0x08 Number per hour
0x10 Global limit
0x20 Byte limit (if not set, it concerns a packet-related limit)
0x40 Limit applies only in receiving direction
0x80 limit applies only in transmission direction
Threshold Exceeded limit value of the trigger limit
Action Bit field, which specifies all implemented actions. At present the following values are
defined:
0x00000001 Accept
0x00000100 Reject
0x00000200 Connect filter
0x00000400 Internet- (Default route-) filter
0x00000800 Drop
0x00001000 Disconnect
0x00004000 Block source address
0x00020000 Block destination address and port
0x20000000 Send SYSLOG notification
0x40000000 Send SNMP trap
0x80000000 Send email
Element Element meaning
