field, the departure air-
port identifier will replace
the ARP field, and POS
coordinates will reflect
selected runway thresh-
old. (Figure 3-4)
4. ENTER Key - DEPRESS.
5. POS Coordinates - VER-
IFY coordinates high-
lighted by the cursor on
the Initialization Page.
(Figure 3-5)
6. ENTER Key - DEPRESS.
If AFIS is not installed, the
display will automatically
advance to the FLIGHT
PLAN LIST Page. The cur-
sor will be positioned over
the first Flight Plan Number
that originates with the same
airport or runway identifier as
entered on the INITIALIZA-
TION Page (Figure 3-6).
Stored Flight Plans are refer-
enced according to
Departure and Destination
pairs and are automatically
sequenced in alphabetical
order on the FLIGHT PLAN
LIST Page. The cursor may
be placed over the desired
FPL number. To review the
FPL press ENTER.
If AFIS/ACARS is installed,
the display will advance to
the AFIS FPL Page or the ACARS Initialization Page after the sys-
tem is initialized.
System Operation
3-4
GNS-XLS Flight Management System
Rev. 8
Apr/00
WAYPOINT RW19R
KSNA
POS N 33 40.89
W117 51.90
OM19R RW19R
RW01L
RW01R
RW19L
DATABASE WPT 4/8
>
<
<
Figure 3-4
DATE 01 JUN 00
GMT 18:42
IDENT RW19R
POS N 33 40.89
W117 51.90
17960-0102 SM06
INITIALIZATION
>
>
>
Figure 3-5
>
>
KABQ KMSY 1
KDAL KHPN 6
KDAL KSFO 8
KHPN KORD 2
KHPN KORD 9
KLAX KSTL 4
KPRC KSNA 3
KSNA KHPN 7
>
FLIGHT PLAN LIST 1/1
Figure 3-6
